[*] posted on 2-26-2018 at 09:49 PM
PTW Playa - evolution 2


Big posts with lots of words and pictures are difficult to post from my phone without crashing. Bear with me, I'll get there with several posts.



Short story.

I wanted a big buggy. I bought the Popeye the Welder, Playa buggy and built a fork for Bigfoot lite tires.


[img][/img]

[img][/img]

More to come.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 2-26-2018 at 09:49 PM


Long story


Well since November I have managed to remained quiet about this...

I am the new owner of the Popeye the Welder Playa buggy. Some things have changed, so read on.

Originally Popeye made the Playa buggy and the Viper for Mike (MDK) in Idaho. When Mike sold the Viper buggy it sold with the beach racer tires and the swan neck that fit both the Viper and the Playa buggies.

Back in November Blitzhound, John ,contacted me to see if I was interested in purchasing a buggy that he recently picked up. John knew I was looking for a full sized buggy with big tires on it. John had bought the playa buggy on barrow tires from MDK in hopes that it would fit his brother. The playas width tuned out to be too narrow for his brother.

John offered it up to me but he was keeping the sysmic rims that were originally on the buggy. I would get it on standard black Peter Lynn wheels and ribbed barrow tires.

There was some miscommunication about the sizing of the buggy. John gave me the measurement of between the buggies metal rails, he measured it without the padding, and I was assuming it was with padding and the seat. After I got the buggy I also realized that a Peter lynn divine harness adds about 1.25-1.5" to the width of your hips, right where the siderails hit me.

I first realized that the buggy would need to be widened I removed the side name plates and the rear back support (added by MDK?). I moved the rear siderails to the outside of the axle mounts. This was still not enough. I ended up adding 3/8 to 1/2" at the back of the buggy and 1 to 1-1/8" at the front. I decided to do these as spacers vs cutting off the axle plates to relocate and re-weld them. I would have needed to extend the siderails at the swan neck to add to the spacing. Hopefully the spacers will work properly and still allow the buggy to be returned to its original state. The thicker front spacers are hollow rectangular stainless steel tubing to save on weight.

After I got my spacing sorted out I made a new cross bar before the axle to strap the seat too (this also needed to be wider) I adjusted the buggy so it was set up on the barrow tires. This buggy sits really low compared to my Flexifoil Navaro.


[img][/img]


[img][/img]




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 2-26-2018 at 09:50 PM


I measured out the wheelbase with the barrow tire for reference when I would add the Bigfoot lite tires.

Next I purchased Bigfoot lites (Nanco 21x12x8) and put them on a set of Peter Lynn plastic wheels that I had extra. I also got 45 degree valve stems to easier access then while inflating. I had trouble mounting one of them because the two seating surfaces were not concentric. I ended up removing the valve core. Modifying my inflater to clamp into the stem and also have a 90 degree on/off valve. I coated the beads with Windex and manipulated the beads until I got air into it. Removing the valve core meant that I could quickly depressurise the tire and rim to prevent damage to the rim at the higher seating pressure.

I removed the barrow front fork and wheel. Then I put the Nanco bfl's on the rear axle and placed the front wheel in approximate position according to my previous wheelbase dimension. I ended up adjusting the original swan neck from its lower adjustment point up to its upper adjustment angle. I then took more measurements of the seat height and swan neck angles.....

Hopefully at the spring SOBB event I will be able to borrow John Ellis's tire grooving tool to add some cuts for more side grip.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 2-26-2018 at 09:50 PM


I played with these numbers and previous buggy drawings that I had done at work on theoretical dream buggies created in Solidworks. I then designed a fork that I liked the styling of. The fork was inspired by a Libre Majestic and GT Rapide++.

I then purchased 1" sch 10 304 stainless steel pipe
(1.32x0.11 wall). I polished it out, packed it with sand and static bent it on my works Ercolina CE40 rolling bending machine. Cut it to my full sized drawing. Then I talked my employer into cutting the 7 parts I needed for my fork on the companies water jet cutter. I polished all these pieces out at my work before welding them together. The bottom of the axle plate is flat to the ground, the photo angle makes it appear to angle downward, it doesn't...

[img][/img]



[img][/img]

[img][/img]


You may notice the ETC several places on the fork. I figured that since this is a PTW buggy (Popeye The Welder) that as a semi joke I would have ETC on my fork. ETC could stand for (Eric The Copycat) or (Eric The Creator)...

I created a basic fixture/jig to fit and weld the upper crown pieces to the lower bent legs. Then I created a
fixture/jig for adding the lower axle plates and foot peg plates. I welded everything up.

I purchased one of the monster scooter MB165 front fenders. To modify it I ended up using 2" of soft foam inbetween the tire and the fender. I strapped around the circumference with a ratchet strap to compress the center ridge of the fender and flare the outer edges wider. This was not easy. It required a lot of heat with a great gun claiming a high heat of 1100 degree. And also took a bunch of time heating and clamping and re-tightening. I did over heat it in several places and I needed to re-paint the fender to get rid of some of the lighter red color spots. I used rust-olium safety red enamel. I then tried to spray lacquer clear coat over it. The combo of enamel and lacquer immediately crackled and crazed. I sanded it out with 800 grit and then decided I liked the matte look. I think it actually looks nice with the sheen of the buggy bags side rail covers. I do worry that the fender is too tight of fit and may suck up sand and propel it forward and up. Moving the axle forward a position on the fork should eliminate that problem but not look as fitted




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 2-26-2018 at 09:51 PM


I re-assembled the buggy to weigh it before and after the wheel swap. It weighed 92lbs on barrows and weighs 102lbs on Bigfoot lites with a fender.

I repolished everything back up and re-assembled the buggy. Many parts only got polished so much, the rear axle has many dings and pock marks from either the Alvord playa surface or traveling on a vehicle.

I still need to add the side plates, carbon belly pan and under rod for my AQR system.


[img][/img]


[img][/img]


[img][/img]


[img][/img]

I am pleased with how the buggy came out visually. I still need to take it out for my maiden voyage on it. Hopefully it will ride reasonably. I also hope that Carlos "Popeye" finds my modifications acceptable.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
Windstruck


Avatar


Posts: 3010
Registered: 5-16-2015
Location: Park City, UT, USA
Member Is Offline

Mood: Building up the stoke for IBX 2020!

[*] posted on 2-27-2018 at 03:28 AM


Wow! She is a beauty. Nice work, and a fine story to read through. Congratulations. She will be a true pleasure to ride in. I am always most interested in reading about such "creative" journeys. "Creative" since copycat hardly seems to give it justice. I particularly liked the trapazoidal slits on the brace of your front fork; that was a great touch.

I don't blame John one bit for holding onto those Sysmic rims. Down the road grabbing a set of them for yourself would really pimp out this ride.




SS kites:
Born-Kite RaceStar+ (3.0m)
Born-Kite RaceStar (5.0m, 7.0m, 9.0m, 11.0m)
Born-Kite NasaStar-4 (2.5m)

Buggy:
Hybrid - nose & tail PL BF+ with wide rear axle; midsection VTT rail & seat kit; two sets of Sysmic rims (BigFoots and 6-ply trailer tires); AQR

NAPKA Member US2815
SWATK Member UT0003
View user's profile View All Posts By User
RedSky


Avatar


Posts: 1369
Registered: 9-7-2009
Member Is Offline


[*] posted on 2-27-2018 at 03:19 PM


Your posts read like the lyrics to Johnny Cash' "one piece at a time", except yours turned out to be a stunner! Nice work, truly nice work.
Popeye will approve for sure. LOve that sand guard. Kinda jealous. I'd like that for my bug. You're forgiven for keeping this hidden from us these past few months. Welcome to the exclusive PTW club. :thumbup: :thumbup: :thumbup:

PS: Carl is of a slender build. I had to remove the padding on mine just to squeeze in, but using depower meant they weren't needed anyway...and as a consequence, there's more chrome on display. :D

LOve it


View user's profile View All Posts By User
abkayak


Avatar


Posts: 2181
Registered: 1-7-2012
Location: a.b. NY
Member Is Offline

Mood: loving life and becoming wise in simplicity

[*] posted on 2-27-2018 at 07:33 PM


yea nice bug:thumbup::thumbup:
forks great,,matte really works
all in on the ETC:thumbup:




US-31...Cquad set/ 2.6 Viper/ 2.9m Reactor/ 3.3 Buster/ 3.5m Bullet/ 3.6 Beamer/ 4m Buster/ 4m Ikon dp/ 4.5 Bullet/ 4.9m Blade/ 5.6 Twister/ 6.6m Blade/ 7.3 Frenzy/ 7.5 Apex/ 9m Fuel/ 13m Pulse/ Phantom I 9,12,15,18/ 2 Flexibugs/ PL Comp XR/ PL Big Foot/ landboards
View user's profile View All Posts By User
Chook


Avatar


Posts: 128
Registered: 10-25-2009
Location: Esperance Western Australia
Member Is Offline

Mood: I work at home from 8.00am to 12 knots

[*] posted on 2-28-2018 at 06:10 AM


Looks great, very well done. :thumbup:

I always like a low CofG (seat height) so I can hold down more kite.


Chook_thumb_JPG_4d38fddf1bbccb5ba96c21550ac85659.jpg - 49kB




Modified Sysmic S2 Buggys
7m R1
8m R1 2
11m R1
15m R1
15m Chrono 2
18m Chrono
18m ELF
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 2-28-2018 at 11:17 PM


Thank you all, and others by u2u and email for your kind words. I like Johnny cash and take no offence to my story sounding that way. Just the facts...I usually get a few 15-30 minutes time spans within a day that "my projects" happen in. They are always fabrication related and quite often kite related. I just like building things and I don't mind documenting it to possibly help others figure out how to do something similar. I'm currently working on side plates and belly pan installation. Also some "bling" may be in my future.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
Windstruck


Avatar


Posts: 3010
Registered: 5-16-2015
Location: Park City, UT, USA
Member Is Offline

Mood: Building up the stoke for IBX 2020!

[*] posted on 3-1-2018 at 06:23 AM


Quote: Originally posted by eric67m


Also some "bling" may be in my future.



That's what I'm talking about!







SS kites:
Born-Kite RaceStar+ (3.0m)
Born-Kite RaceStar (5.0m, 7.0m, 9.0m, 11.0m)
Born-Kite NasaStar-4 (2.5m)

Buggy:
Hybrid - nose & tail PL BF+ with wide rear axle; midsection VTT rail & seat kit; two sets of Sysmic rims (BigFoots and 6-ply trailer tires); AQR

NAPKA Member US2815
SWATK Member UT0003
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 3-1-2018 at 07:44 PM


I added the side name plates and the carbon belly pan. I still need to trim my zip ties.

[img][/img]


[img][/img]


[img][/img]


[img][/img]




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
abkayak


Avatar


Posts: 2181
Registered: 1-7-2012
Location: a.b. NY
Member Is Offline

Mood: loving life and becoming wise in simplicity

[*] posted on 3-2-2018 at 06:37 AM


:thumbup::thumbup:really great plate
scuff marks already?




US-31...Cquad set/ 2.6 Viper/ 2.9m Reactor/ 3.3 Buster/ 3.5m Bullet/ 3.6 Beamer/ 4m Buster/ 4m Ikon dp/ 4.5 Bullet/ 4.9m Blade/ 5.6 Twister/ 6.6m Blade/ 7.3 Frenzy/ 7.5 Apex/ 9m Fuel/ 13m Pulse/ Phantom I 9,12,15,18/ 2 Flexibugs/ PL Comp XR/ PL Big Foot/ landboards
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 3-2-2018 at 07:04 AM


Quote: Originally posted by abkayak

scuff marks already?


Both the buggy and the Dragonfly carbon products, carbon fiber belly pans are used. I put the previously scratched side down again.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
popeyethewelder




Posts: 1182
Registered: 3-19-2005
Location: Lincoln, England
Member Is Offline


[*] posted on 3-22-2018 at 02:20 PM
Well done Eric






Popeyethewelder
Riding a buggy of some description
Powered by (unsponsored) PL Vapors
Rolling on Landsegler
Popeyethewelder
View user's profile Visit user's homepage View All Posts By User
popeyethewelder




Posts: 1182
Registered: 3-19-2005
Location: Lincoln, England
Member Is Offline


[*] posted on 3-22-2018 at 02:22 PM






Popeyethewelder
Riding a buggy of some description
Powered by (unsponsored) PL Vapors
Rolling on Landsegler
Popeyethewelder
View user's profile Visit user's homepage View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 3-22-2018 at 03:10 PM


Thank you for your approval Popeye.

In looking through old pictures of the buggy I noticed that I have the name plates on the wrong sides because the blue stars should be at the back to line up with the back center plate (not currently on).

The other question is when I got the buggy it had a rear cross brace or backrest which it appears Mike had made by somebody else. It is not in the earlier pictures that I have found. Is this correct?




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
RedSky


Avatar


Posts: 1369
Registered: 9-7-2009
Member Is Offline


[*] posted on 3-22-2018 at 05:22 PM


Popeye has tried posting a reply about three times but the text was not there for some reason. He has asked me to post the following message
View user's profile View All Posts By User
RedSky


Avatar


Posts: 1369
Registered: 9-7-2009
Member Is Offline


[*] posted on 3-22-2018 at 05:40 PM


Well done Eric, what an enormous amount of work you have had to do, you done well.

I am positive it will ride well, if I am being hyper critical I would lengthen the down section to lower the front of the buggy another 1 1/2 or 2" but that is just my preference. I tried a huffy front fender on the SuperBug I found as the sand whipped rounds at speed under the guard, it would shoot out the top front and I would be riding through a cloud of sand over 50mph, that's not ideal, so I soon moved on from that, with experience a decent gap between the tyre and the fender works better.

Look forward to hearing how you get on, good luck.
View user's profile View All Posts By User
popeyethewelder




Posts: 1182
Registered: 3-19-2005
Location: Lincoln, England
Member Is Offline


[*] posted on 3-22-2018 at 11:43 PM


Thanks Tom, I was trying to reply with my phone and failing


To your other question, I did not put a cross brace on the Playa or Viper

http://popeyethewelder.com/popeyethewelder/ptw-buggies/ptw-p...

http://popeyethewelder.com/popeyethewelder/ptw-buggies/ptw-v...




Popeyethewelder
Riding a buggy of some description
Powered by (unsponsored) PL Vapors
Rolling on Landsegler
Popeyethewelder
View user's profile Visit user's homepage View All Posts By User
popeyethewelder




Posts: 1182
Registered: 3-19-2005
Location: Lincoln, England
Member Is Offline


[*] posted on 3-22-2018 at 11:44 PM


I tried a HUGGY front fender on the SuperBug I found as the sand whipped rounds at speed under the guard, it would shoot out the top front and I would be riding through a cloud of sand over 50mph, that's not ideal, so I soon moved on from that, with experience a decent gap between the tyre and the fender works better.

http://popeyethewelder.com/popeyethewelder/ptw-buggies/the-p...




Popeyethewelder
Riding a buggy of some description
Powered by (unsponsored) PL Vapors
Rolling on Landsegler
Popeyethewelder
View user's profile Visit user's homepage View All Posts By User
RedSky


Avatar


Posts: 1369
Registered: 9-7-2009
Member Is Offline


[*] posted on 3-23-2018 at 02:41 AM


Looking at those pictures made me realise that I need to polish up my Dominator.
View user's profile View All Posts By User
Windstruck


Avatar


Posts: 3010
Registered: 5-16-2015
Location: Park City, UT, USA
Member Is Offline

Mood: Building up the stoke for IBX 2020!

[*] posted on 3-23-2018 at 10:23 AM


Van's got a few sets of 4x8 Sysmics. Just sayin....

http://www.powerkiteforum.com/viewthread.php?tid=34110#pid32...

:evil:




SS kites:
Born-Kite RaceStar+ (3.0m)
Born-Kite RaceStar (5.0m, 7.0m, 9.0m, 11.0m)
Born-Kite NasaStar-4 (2.5m)

Buggy:
Hybrid - nose & tail PL BF+ with wide rear axle; midsection VTT rail & seat kit; two sets of Sysmic rims (BigFoots and 6-ply trailer tires); AQR

NAPKA Member US2815
SWATK Member UT0003
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 3-23-2018 at 11:25 AM


Quote: Originally posted by Windstruck
Van's got a few sets of 4x8 Sysmics. Just sayin....

http://www.powerkiteforum.com/viewthread.php?tid=34110#pid32...

:evil:


Yah, yah. I hear you.




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 4-7-2018 at 01:22 PM


I finally got out for a short run between yesterday's no wind and today's wind storm. Yesterday I couldn't keep my 12M peak in the air. Today my 1.5m was enough to get moving and at times was too much. I got about 45 minutes in before it started to rain. The buggy handled really well. The back end would break loose before the front. I could possibly move my seat back a bit.

[img][/img]


My daughter took some pictures from a ways away. This is one of the better ones.

[img][/img]


I am pleased with my rear rack. It's super stable on the freeway and bumpy ocean access roads.

[img][/img]




Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
sand flea


Avatar


Posts: 591
Registered: 12-2-2010
Location: Portland Oregon
Member Is Offline

Mood: non significant wind chaser

[*] posted on 4-7-2018 at 02:02 PM


Glad you got some seat time Eric
Buggy looks great!
Did you groove your tires!
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 4-7-2018 at 02:12 PM


Yes, I did groove my tires. I borrowed a tire groover that I will return to its owner at spring SOBB. I put the buggies axle up on a saw horse so I could rotate the tire. I did 8 grooves spaced with 1/2" masking tape with the tool.



Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
Demoknight


Avatar


Posts: 1120
Registered: 6-7-2013
Location: Chicago, IL
Member Is Offline

Mood: ADIDAK

[*] posted on 4-24-2018 at 12:20 PM


Eric, does that front fender throw sand out the top of the wheel? I have noticed when I first put a fender on my front wheel, if I had it too close to the wheel, the sand would just get thrown up and out the top and blow back into my face anyway.



NAPKA US8008

Kites:

Flysurfer Speed 3 Deluxe 19m
Peter Lynn Charger 2 12m
Peter Lynn 2013 Reactor 5.5m
Peter Lynn 2013 Reactor 8.6m
Prism Tensor 5.0m

Ride:
Weird Beard VTT Custom
View user's profile View All Posts By User
eric67m


Avatar


Posts: 493
Registered: 9-11-2015
Location: Monroe, Washington
Member Is Offline


[*] posted on 4-25-2018 at 07:25 AM


I honestly could not tell. The sand was blowing across the surface of the wet packed surface. Hopefully I'll get more seat time at SOBB.



Flying A mixed quiver of Flysurfer Peak kites.

Rollin in the Popeye The Welder Playa buggy.
View user's profile View All Posts By User
ColinW




Posts: 171
Registered: 4-12-2015
Location: Victoria BC
Member Is Offline


[*] posted on 5-6-2018 at 11:09 AM


Hey Eric
Fantastic work on your new ride!
I see (I think?) that you have some spacers in between your down tube and the clamping plates on your side rails.
Could you tell me what they are made of?
I'm going to need something similar on my Pagona.
As a carpenter, I was thinking of just using some hardwood blocks, but I'll bet there would be better options.
Mine will have holes drilled, as the bolts go through the swan neck.
Looking forward to seeing you at SOBB, and drooling over your new stainless:o
colin
View user's profile View All Posts By User
 Pages:  1

  Go To Top

Hosted by: Mad Moose Studio
